WO2023196913A2 - Methods of treating ankylosing spondylitis - Google Patents
Methods of treating ankylosing spondylitis Download PDFInfo
- Publication number
- WO2023196913A2 WO2023196913A2 PCT/US2023/065452 US2023065452W WO2023196913A2 WO 2023196913 A2 WO2023196913 A2 WO 2023196913A2 US 2023065452 W US2023065452 W US 2023065452W WO 2023196913 A2 WO2023196913 A2 WO 2023196913A2
- Authority
- WO
- WIPO (PCT)
- Prior art keywords
- sequence
- pharmaceutical composition
- izokibep
- administered
- amino acid
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Ceased
Links
Classifications
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K16/00—Immunoglobulins [IG], e.g. monoclonal or polyclonal antibodies
- C07K16/18—Immunoglobulins [IG], e.g. monoclonal or polyclonal antibodies against material from animals or humans
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K16/00—Immunoglobulins [IG], e.g. monoclonal or polyclonal antibodies
- C07K16/18—Immunoglobulins [IG], e.g. monoclonal or polyclonal antibodies against material from animals or humans
- C07K16/24—Immunoglobulins [IG], e.g. monoclonal or polyclonal antibodies against material from animals or humans against cytokines, lymphokines or interferons
- C07K16/244—Interleukins [IL]
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61K—PREPARATIONS FOR MEDICAL, DENTAL OR TOILETRY PURPOSES
- A61K38/00—Medicinal preparations containing peptides
- A61K38/16—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P19/00—Drugs for skeletal disorders
- A61P19/02—Drugs for skeletal disorders for joint disorders, e.g. arthritis, arthrosis
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61P—SPECIFIC THERAPEUTIC ACTIVITY OF CHEMICAL COMPOUNDS OR MEDICINAL PREPARATIONS
- A61P37/00—Drugs for immunological or allergic disorders
- A61P37/02—Immunomodulators
- A61P37/06—Immunosuppressants, e.g. drugs for graft rejection
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K14/00—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof
- C07K14/195—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof from bacteria
- C07K14/305—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof from bacteria from Micrococcaceae (F)
- C07K14/31—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof from bacteria from Micrococcaceae (F) from Staphylococcus (G)
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K14/00—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof
- C07K14/195—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof from bacteria
- C07K14/315—Peptides having more than 20 amino acids; Gastrins; Somatostatins; Melanotropins; Derivatives thereof from bacteria from Streptococcus (G), e.g. Enterococci
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61K—PREPARATIONS FOR MEDICAL, DENTAL OR TOILETRY PURPOSES
- A61K39/00—Medicinal preparations containing antigens or antibodies
- A61K2039/505—Medicinal preparations containing antigens or antibodies comprising antibodies
-
- A—HUMAN NECESSITIES
- A61—MEDICAL OR VETERINARY SCIENCE; HYGIENE
- A61K—PREPARATIONS FOR MEDICAL, DENTAL OR TOILETRY PURPOSES
- A61K39/00—Medicinal preparations containing antigens or antibodies
- A61K2039/545—Medicinal preparations containing antigens or antibodies characterised by the dose, timing or administration schedule
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K2317/00—Immunoglobulins specific features
- C07K2317/30—Immunoglobulins specific features characterized by aspects of specificity or valency
- C07K2317/31—Immunoglobulins specific features characterized by aspects of specificity or valency multispecific
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K2317/00—Immunoglobulins specific features
- C07K2317/70—Immunoglobulins specific features characterized by effect upon binding to a cell or to an antigen
- C07K2317/76—Antagonist effect on antigen, e.g. neutralization or inhibition of binding
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K2318/00—Antibody mimetics or scaffolds
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K2318/00—Antibody mimetics or scaffolds
- C07K2318/20—Antigen-binding scaffold molecules wherein the scaffold is not an immunoglobulin variable region or antibody mimetics
-
- C—CHEMISTRY; METALLURGY
- C07—ORGANIC CHEMISTRY
- C07K—PEPTIDES
- C07K2319/00—Fusion polypeptide
- C07K2319/31—Fusion polypeptide fusions, other than Fc, for prolonged plasma life, e.g. albumin
Definitions
- the application relates generally to novel dosing regimen for treating an inflammatory arthritis, by administration of a therapeutically effective amount of pharmaceutical composition comprising an engineered bispecific fusion protein, wherein the bispecific fusion protein comprises an IL-17A binding motif and an albumin binding motif.
- XML eXtensible Markup Language
- Ankylosing spondylitis is a chronic, progressive, inflammatory disease with considerable impact on patient functioning, well-being, and disability.
- Axial spondyloarthritis (AxSpA) is a type of spondyloarthritis that affects mainly the spine and pelvic joints.
- r-AxSpA radiographic axial spondyloarthritis
- R-AxSpA is chronic, inflammatory disease that impacts the axial skeleton or sacroiliac joints and spine.
- Non-radiographic axial spondyloarthritis is a type of arthritis in the spine.
- AS ankylosing spondylitis
- AS As a chronic disease of the axial skeleton and large peripheral joints, AS causes inflammatory back pain and stiffness and it is associated with other inflammatory diseases of the skin, eyes and intestines. AS is difficult to diagnose in its early stages and is often an overlooked cause of persistent back pain in young adults. In severe cases, AS may result in complete spinal fusion, causing extreme physical limitation. Thus, there remains a need for a safe and effective treatment for AS. As the disease progresses, patients with AS experience pain, joint stiffness, and the eventual loss of spinal mobility. These clinical symptoms and subsequent disease progression result in functional limitations and impairment in health-related quality of life (HRQOL) (Dagfinrud et al. Ann Rheum Dis 2004:63:1605-10; Bostan et al.
- HRQOL health-related quality of life
- Ankylosing spondylitis can be treated by compositions that include comprising a bispecific fusion protein, wherein the bispecific fusion protein comprises an IL-17A binding motif and an albumin binding motif.
- the invention provides novel methods for the treatment of AS by administering once a week to a patient a therapeutically effective amount of pharmaceutical composition comprising a bispecific fusion protein, wherein the bispecific fusion protein comprises an IL-17A binding motif and an albumin binding motif.
- the invention also provides a bispecific fusion protein for use in the treatment of AS, wherein the bispecific fusion protein comprises an IL-17A binding motif and an albumin binding motif.
- the invention provides use of a bispecific fusion protein in the production of a medicament for the treatment of AS, wherein the bispecific fusion protein comprises an IL-17A binding motif and an albumin binding motif.
- the interleukin-17 (IL-17) family is a pro-inflammatory cytokine family that contributes to the pathogenesis of several inflammatory diseases.
- a major source of IL-17 is a lineage of T cells known as T helper 17 cells (Th17 cells), which are distinct from the classical Th1 and Th2 cell subsets. Results of studies in mouse models and in humans have identified a key role of IL-17 and Th17 cells in the pathogenesis of inflammation and autoimmunity as well as in host defense against certain pathogens.
- IL-17 and Th17 cells are considered to be interesting targets for the treatment of several chronic inflammatory diseases such as psoriasis, rheumatoid arthritis (RA), ankylosing spondylitis (AS), systemic lupus erythematosus (SLE) and multiple sclerosis (MS) (Miossec and Kolls, 2012, Nat Rev Drug Discov 11:763-7).
- the disulfide-linked homodimeric cytokine IL-17A is a member of the IL-17 family, which also includes IL-17B, IL-17C, IL-17D, IL-17E and IL-17F.
- IL-17A and IL-17F show the highest amino acid sequence homology to each other (50%) and they bind to the same receptors: IL-17 receptor A (IL-17RA) and IL-17 receptor C (IL-17RC). Furthermore, IL-17A can be expressed with IL-17F as a heterodimer. Although IL-17A and IL-17F share high amino acid sequence homology, they perform distinct functions. IL-17A is involved in the development of autoimmunity, inflammation and tumors and also plays important roles in the host defense against bacterial and fungal infections. IL-17F, on the other hand, is mainly involved in mucosal host defense mechanisms (Iwakura et al, 2011, Immunity 34:149-62).
- IL-17A When IL-17A is secreted, it promotes the production of a variety of proinflammatory cytokines, chemokines, antimicrobial peptides and metalloproteinases (MMPs) from fibroblast, endothelial and epithelial cells.
- MMPs metalloproteinases
- One important action of IL-17A is to induce granulopoiesis and neutrophil recruitment to inflammatory sites. However, if uncontrolled, this reaction may lead to chronic inflammation with tissue destruction and neovascularization (Iwakura et al. 2008, Immunol Rev 226:57-79; Reynolds et al.2010, Cytokine Growth Factor Rev 21:413-23).
- IL-17A is central in the pathogenesis of psoriasis, a common chronic inflammatory skin disease affecting about 2.5% of the worldwide population (reviewed in Chiricozzi and Krueger, 2013, Expert Opin. Investig. Drugs 22(8):993-1005). Studies in patients with RA have shown that IL-17A positive cells are present in the inflamed synovium. In a mouse model of RA, the clinical scores were severely aggravated by administration of IL-17A via intra-articular gene transfer (Lubberts et al. 2002, Inflamm Res 51:102-4).
- IL-17A Increased levels of IL-17A have been shown to be clinically correlated with various ocular inflammatory diseases, such as uveitis, scleritis and dry eye disease (DED) in patients suffering from arthritis (Kang et al. 2011, J Korean Med Sci 26:938-44). Recent studies have showed IL-17 and IFN ⁇ positive cells in clinical specimens of coronary atherosclerosis suggesting a local effect on vessel dysfunction (Eid et al. 2009, J Cardiothorac Surg 4:58). Thus, the involvement of IL-17A in several different autoimmune and inflammatory diseases suggests a wide applicability of therapeutics targeting IL- 17A. Targeting of IL-17A or its receptors is the most direct way to block IL-17A-mediated functions.
- IL-17 receptor mediated signaling is also under investigation in the clinic, including the human monoclonal anti- IL-17RA antibody brodalumab for treatment of psoriasis, RA and asthma (Hu et al.2011, Ann N Y Acad Sci 1217:60-76).
- clinical efficacy of IL-17A-inhibition has been proven in different diseases, notably in psoriasis, and the safety profile, including phase II and phase III data, shows good tolerability for IL-17A inhibitors (Genovese et al. 2010, Arthritis Rheum 62:929-39 and Hueber et al.2010, Sci Transl Med 2:52ra72).
- Serum albumin is the most abundant protein in mammalian sera (40 g/l; approximately 0.7 mM in humans), and one of its functions is to bind molecules such as lipids and bilirubin (Peters, Advances in Protein Chemistry 37:161, 1985). Serum albumin is devoid of any enzymatic or immunological function. Furthermore, human serum albumin (HSA) is a natural carrier involved in the endogenous transport and delivery of numerous natural as well as therapeutic molecules (Sellers and Koch-Weser, Albumin Structure, Function and Uses, eds Rosenoer et al, Pergamon, Oxford, p 159, 1977).
- HSA human serum albumin
- serum albumin is directly proportional to the size of the animal, where for example human serum albumin has a half life of 19 days and rabbit serum albumin has a half life of about 5 days (McCurdy et al, J Lab Clin Med 143:115, 2004).
- HSA is widely distributed throughout the body, in particular in the interstitial and blood compartments, where it is mainly involved in the maintenance of osmolarity.
- albumins are single- chain proteins comprising three homologous domains and in total 584 or 585 amino acids (Dugaiczyk et al, Proc Natl Acad Sci USA 79:71, 1982).
- Albumins contain 17 disulfide bridges and a single reactive thiol, cysteine in position 34, but lack N-linked and O-linked carbohydrate moieties (Peters, 1985, supra; Nicholson et al, Br J Anaesth 85:599, 2000).
- Several strategies have been reported to either covalently couple proteins directly to serum albumins or to a peptide or protein that will allow in vivo association to serum albumins. Examples of the latter approach have been described e.g. in WO91/01743, in WO01/45746 and in Dennis et al (J Biol Chem 277:35035-43, 2002).
- the first document describes inter alia the use of albumin binding peptides or proteins derived from streptococcal protein G (SpG) for increasing the half life of other proteins.
- SpG streptococcal protein G
- the idea is to fuse the bacterially derived, albumin binding peptide/protein to a therapeutically interesting peptide/protein, which has been shown to have a rapid elimination from blood.
- the thus generated fusion protein binds to serum albumin in vivo, and benefits from its longer half-life, which increases the net half-life of the fused therapeutically interesting peptide/protein.
- WO01/45746 and Dennis et al relate to the same concept, but here, the authors utilize relatively short peptides to bind serum albumin.
- the peptides were selected from a phage displayed peptide library.
- the structure is highly repetitive with several structurally and functionally different domains (Guss et al, EMBO J 5:1567, 1986), more precisely three Ig-binding domains and three serum albumin binding domains (Olsson et al, Eur J Biochem 168:319, 1987).
- the structure of one of the three serum albumin binding domains in SpG has been determined, showing a three-helix bundle fold (Kraulis et al, FEBS Lett 378:190, 1996, Johansson et al, J. Biol. Chem.277:8114-20, 2002).
- a 46 amino acid motif was defined as ABD (albumin binding domain) and has subsequently also been designated G148-GA3 (GA for protein G-related albumin binding).
- albumin binding variants of the 46 amino acid motif ABD are disclosed.
- G148 Streptococcal protein G strain 148
- Goetsch et al Clin Diagn Lab Immunol 10:125-32, 2003.
- the authors behind the study were interested in utilizing the T-cell epitopes of G148 in vaccines, i.e. to utilize the inherent immune-stimulatory property of the albumin binding region.
- Goetsch et al additionally found a B-cell epitope, i.e. a region bound by antibodies after immunization, in the sequence of G148.
- the albumin binding domain G148 is as such unsuitable for use in such compositions due to its abovementioned immune-stimulatory properties. Furthermore, since tissue penetration rate is negatively associated with the size of the molecule, a relatively large antibody molecule inherently has poor tissue distribution and penetration capacity. Moreover, although antibodies are widely used in a variety of routine contexts owing to high affinity and specificity to a multitude of possible antigens, such as for analytical, purification, diagnostic and therapeutic purposes, they still suffer from several drawbacks.
- the IL-17A binding motif includes and/or consists of an amino acid sequence selected from: i) EX 2 DX4AX 6 X7EIX 10 X11LPNL X16X17X18QX 20 X21AFIX25 X26LX 28 X29 (SEQ ID NO.1) wherein, independently from each other, X 2 is selected from A, H, M and Y; X4 is selected from A, D, E, F, K, L, M, N, Q, R, S and Y; X 6 is selected from A, Q and W; X7 is selected from F, I, L, M, V, W and Y; X 10 is selected from A and W; X11 is selected from A, D,
- the function of any polypeptide is dependent on the tertiary structure of the polypeptide. It is therefore possible to make minor changes to the sequence of amino acids in a polypeptide without affecting the function thereof.
- the disclosure encompasses modified variants of the IL-17A binding polypeptide, which are such that the IL-17A binding characteristics are retained.
- the fusion protein or conjugate of this second aspect comprises two monomers of the IL-17A binding polypeptide of the first aspect, whose amino acid sequences may be the same or different, linked by an albumin binding moiety.
- the fusion protein or conjugate comprises two IL-17A binding monomers with an albumin binding moiety between them.
- Said albumin binding moiety may e.g. be a “GA” albumin binding domain from streptococcal protein G, such as “GA3”, or a derivative thereof as described in any one of WO2009/016043, WO2012/004384, WO2014/048977 and WO2015/091957.
- the albumin binding motif consists of an amino acid sequence LAX 3 AKX 6 X 7 ANX 10 ELDX 14 YGVSDFYKRLIX 26 KAKTVEGVEALKX 39 X 40 ILX 43 X 44 LP (SEQ ID.
- the bispecific fusion protein is izokibep. Izokibep may also be referred to as ABY-035 or IMG-020.
- Izokibep is a small protein therapeutic designed to inhibit interleukin-17A (IL-17A) with higher potency and the potential for greater tissue penetration due to its markedly smaller size when compared to traditional monoclonal antibodies. Izokibep has enhanced potency as it blocks the homodimeric IL-17A target protein by binding to both sub-units simultaneously with a very high affinity. In certain embodiments, KD for izokibep binding to IL-17A is as low as 0.3 pM. Klint et al. Izokibep – Preclinical Development and First-in-Human Study of a Novel IL-17A Neutralizing Affibody Molecule in Patients with Plaque Psoriasis.
- the two IL-17A binding domains bind to the dimeric IL-17A homodimers at the same time, and the two IL17A binding domains are connected by albumin binding domain.
- albumin binding domain increases the half-life of izokibep.
- the half-life of izokibep may be a few days. In certain embodiments, the half-life of izokibep is from about 5 to about 20 days. In certain embodiments, the half-life of izokibep is from about 10 to about 15 days. In certain embodiments, the half-life of izokibep is about 12 days.
- Izokibep also has a well-established safety profile.
- izokibep is safe for patients up to 3 years without any observed increased risk of infection or any significant increase in anti-drug antibodies (ADAs).
- ADAs anti-drug antibodies
- the presence of or a significant increase in ADAs can impact exposure of the drug and/or the clinical response of the drug in the patients.
- exposures of the drugs are lower compared to other inflammatory conditions.
- the high potency of izokibep to IL-17A, as well as the small molecular size of izokibep, leads to improved tissue penetration and target engagement and therefore provide the potential for differentiated clinically meaningful benefit for patients.
- the size of izokibep is one-tenth (1/10 th ) of those of typical monoclonal IL- 17A antibodies.
- izokibep has quick and therapeutic effects in patients suffering from HS and Psoriatic Arthritis.
- the bispecific fusion protein is SEQ ID. NO.3.
- the bispecific fusion protein sequence comprises the peptide described in the amino acid sequence below or a fragment thereof:
- a pharmaceutical composition comprising a therapeutically effective amount of the bispecific fusion protein, preferably izokibep, is administered to a patient suffering from ankylosing spondylitis.
- a pharmaceutical composition of the bispecific fusion protein preferably izokibep.
- the pharmaceutical composition is an injectable solution.
- the bispecific fusion protein, preferably izokibep is administered to the patient subcutaneously.
- the pharmaceutical composition comprises 20 – 200 mg izokibep.
- the pharmaceutical composition comprises 40 mg izokibep. In another embodiment of the invention, the pharmaceutical composition comprises 80 mg izokibep. In another embodiment of the invention, the pharmaceutical composition comprises 160 mg izokibep. In another embodiment of the invention, the pharmaceutical composition comprises at least one additional excipient. In another embodiment of the invention, a pharmaceutical composition comprising a therapeutically effective amount of the bispecific fusion protein, preferably izokibep, is administered to a patient suffering from ankylosing spondylitis once a week. In another embodiment of the invention, a pharmaceutical composition comprising 40 mg izokibep, is administered to a patient suffering from ankylosing spondylitis once a week.
- a pharmaceutical composition comprising 40 mg izokibep, is administered to a patient suffering from ankylosing spondylitis once every two weeks. In another embodiment of the invention, a pharmaceutical composition comprising 80 mg izokibep, is administered to a patient suffering from ankylosing spondylitis once every two weeks. In another embodiment of the invention, a pharmaceutical composition comprising 160 mg izokibep, is administered to a patient suffering from ankylosing spondylitis once a week. In another embodiment of the invention, a pharmaceutical composition comprising 160 mg izokibep, is administered to a patient suffering from ankylosing spondylitis once every two weeks.
- a pharmaceutical composition comprising 160 mg izokibep, is administered to a patient suffering from ankylosing spondylitis once every four weeks.
- the present invention is directed to a novel method for the treatment of AS by administering once a week to a patient a therapeutically effective amount of pharmaceutical composition comprising a bispecific fusion protein, wherein the bispecific fusion protein comprises an IL-17A binding motif and an albumin binding motif.
- a preferred example of the bispecific fusion protein is izokibep (ABY-035 or IMG-020), IL-17 inhibitor, is currently in clinical trials for treatment of AS (Rondon et al., Adv. Funct.
- Izokibep is a bispecific fusion protein comprising two units of an engineered variant of protein Z derived from the B domain of staphylococcal Protein A and structured as a triple ⁇ -helix bundle, with a high affinity for interleukin-17A (IL-17A) and one ABD domain (5 kDa) with high affinity for SA.
- the bispecific fusion protein is SEQ ID. NO.3.
- the bispecific fusion protein sequence comprises the peptide described in the amino acid sequence below or a fragment thereof: IL-17A Binding Motif The invention discloses IL-17A binding motifs, which could for example be used for diagnostic, prognostic and therapeutic applications.
- the IL-17A binding motif consists of an amino acid sequence selected from (SEQ ID NO: 1): i) EX 2 DX 4 AX 6 X 7 EIX 10 X 11 LPNLX 16 X 17 X 18 QX 20 X 21 AFIX 25 X 26 L X 28 X 29 wherein, independently from each other, X 2 is selected from A, H, M and Y; X 4 is selected from A, D, E, F, K, L, M, N, Q, R, S and Y; X 6 is selected from A, Q and W; X7 is selected from F, I, L, M, V, W and Y; X 10 is selected from A and W; X 11 is selected from A, D, E, F, G, L, M, N, Q, S, T and Y; X16 is selected from N and T; X17 is selected from H, W and Y; X 18 is selected from A, D, E, H and V;
- IL-17A binding polypeptides The above definition of a class of sequence related, IL-17A binding polypeptides is based on a statistical analysis of a number of random polypeptide variants of a parent scaffold, that were selected for their interaction with IL-17A in several different selection experiments.
- the identified IL-17A binding motif, or “BM” corresponds to the target binding region of the parent scaffold, which region constitutes two alpha helices within a three-helical bundle protein domain.
- the varied amino acid residues of the two BM helices constitute a binding surface for interaction with the constant Fc part of antibodies.
- the random variation of binding surface residues and subsequent selection of variants have replaced the Fc interaction capacity with a capacity for interaction with IL-17A.
- the function of any polypeptide is dependent on the tertiary structure of the polypeptide. It is therefore possible to make minor changes to the sequence of amino acids in a polypeptide without affecting the function thereof.
- the disclosure encompasses modified variants of the IL-17A binding polypeptide, which are such that the IL-17A binding characteristics are retained.
- an IL-17A binding polypeptide comprising an amino acid sequence with 89% or greater identity to a polypeptide as defined in i).
- the polypeptide may comprise a sequence which is at least 93%, such as at least 96% identical to a polypeptide as defined in i).
- a polypeptide as defined in i.
- an amino acid residue belonging to a certain functional grouping of amino acid residues e.g. hydrophobic, hydrophilic, polar etc
- such changes may be made in any position of the sequence of the IL-17A binding polypeptide as disclosed herein.
- such changes may be made only in the non-variable positions, also denoted scaffold amino acid residues. In such cases, changes are not allowed in the variable positions, i.e. positions denoted with an “X” in sequence i).
- % identity may for example be calculated as follows.
- the query sequence is aligned to the target sequence using the CLUSTAL W algorithm (Thompson et al, Nucleic Acids Research, 22: 4673-4680 (1994)).
- a comparison is made over the window corresponding to the shortest of the aligned sequences.
- the shortest of the aligned sequences may in some instances be the target sequence. In other instances, the query sequence may constitute the shortest of the aligned sequences.
- the amino acid residues at each position are compared and the percentage of positions in the query sequence that have identical correspondences in the target sequence is reported as % identity.
- a polypeptide as defined above wherein, in sequence i), X 2 is selected from A, H and M; X 4 is selected from A, D, E, F, L, M, N, Q, R and Y; X11 is selected from A, D, E, F, G, L, M, N, S, T and Y; X 18 is selected from A, D, E and V; X 20 is selected from A, G, Q and W; X21 is selected from E, F, H, N, R, T, V, W and Y; X25 is selected from A, D, E, G, H, I, L, N, Q, R, S, T and V; and X 28 is selected from I, N and R.
- a polypeptide as defined in the paragraph immediately above wherein in addition, in sequence i), X 16 is T; X 17 is W, X21 is selected from E, F, H, W, T and Y; X 25 is selected from A, D, E, G, H, I, L, N, Q, R, S and T; X 26 is K; and X29 is D.
- Xn and Xm are used herein to indicate amino acids in positions n and m in the sequence i) as defined above, wherein n and m are integers indicating the position of an amino acid within sequence i) as counted from the N terminus.
- X3 and X7 indicate the amino acids in positions three and seven, respectively, from the N-terminal end of sequence i).
- X n may be selected from any one of the listed groups of possible residues and that this selection is independent from the selection of amino acids in Xm, wherein n ⁇ m.
- any of the listed possible residues in position Xn in Table 1 may be independently combined with any of the listed possible residues any other variable position in Table 1.
- sequence i) fulfills at least six of the eleven conditions I-XI: I. X 2 is A; II. X4 is selected from D, E and Q; III. X 6 is A; IV. X7 is selected from F and V; V. X 16 is T; VI. X17 is W; VII. X18 is selected from A and D; VIII. X 20 is W; IX. X 26 is K; X.X 28 is R; and XI. X 29 is D.
- sequence i) fulfills at least seven of the eleven conditions I-XI.
- sequence i) may fulfill at least eight of the eleven conditions I-XI, such as at least nine of the eleven conditions I-XI, such as at least ten of the eleven conditions I-XI, such as all of the eleven conditions I-XI.
- X 2 X 6 , X 2 X 10 or X 6 X 10 are independently AA.
- X 2 X 17 , X 2 X 20 , X 6 X17, X 6 X 20 , X 10 X17 or X 10 X 20 are independently AW.
- X 2 X 28 , X 6 X 28 or X 10 X 28 is AR.
- X 17 X 28 or X 20 X 28 is WR.
- X 17 X 20 is WW.
- sequences of individual IL-17A binding motifs correspond to amino acid positions 8-36 in SEQ ID NO:1-1216 presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence i) corresponds to the sequence from position 8 to position 36 in a sequence selected from the group consisting of SEQ ID NO:1-1216 presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence i) corresponds to the sequence from position 8 to position 36 in a sequence selected from the group consisting of SEQ ID NO:1-66, 1200, 1206 and 1214, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence i) corresponds to the sequence from position 8 to position 36 in a sequence selected from the group consisting of SEQ ID NO:1-66 presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence i) corresponds to the sequence from position 8 to position 36 in a sequence selected from the group consisting of SEQ ID NO:1-35 presented in U.S.
- sequence i) corresponds to the sequence from position 8 to position 36 in a sequence selected from the group consisting of SEQ ID NO:1-27 presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence i) corresponds to the sequence from position 8 to position 36 in a sequence selected from the group consisting of SEQ ID NO:1-10 presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence i) corresponds to the sequence from position 8 to position 36 in a sequence selected from the group consisting of SEQ ID NO:1-7 presented in U.S. Patent No.
- sequence i) corresponds to the sequence from position 8 to position 36 in a sequence selected from the group consisting of SEQ ID NO:1-4 presented in U.S. Patent No. 10,934,335, which is incorporated by reference in its entirety.
- sequence i) corresponds to the sequence from position 8 to position 36 in SEQ ID NO:1 presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- the BM as defined above “forms part of” a three-helix bundle protein domain.
- the sequence of the BM is “inserted” into or “grafted” onto the sequence of the original three-helix bundle domain, such that the BM replaces a similar structural motif in the original domain.
- the BM is thought to constitute two of the three helices of a three-helix bundle, and can therefore replace such a two-helix motif within any three-helix bundle.
- the replacement of two helices of the three-helix bundle domain by the two BM helices has to be performed so as not to affect the basic structure of the polypeptide.
- the overall folding of the Ca backbone of the polypeptide according to this embodiment of the invention is substantially the same as that of the three-helix bundle protein domain of which it forms a part, e.g. having the same elements of secondary structure in the same order etc.
- a BM according to the disclosure “forms part” of a three-helix bundle domain if the polypeptide according to this embodiment of the aspect has the same fold as the original domain, implying that the basic structural properties are shared, those properties e.g. resulting in similar CD spectra.
- the IL-17A binding motif (BM) thus forms part of a three-helix bundle protein domain.
- the BM may essentially constitute two alpha helices with an interconnecting loop, within said three-helix bundle protein domain.
- said three-helix bundle protein domain is selected from domains of bacterial receptor proteins. Non-limiting examples of such domains are the five different three-helical domains of Protein A from Staphylococcus aureus, such as domain B, and derivatives thereof.
- the three-helical bundle protein domain is a variant of protein Z, which is derived from domain B of staphylococcal Protein A.
- the IL-17A binding polypeptide may comprise an amino acid sequence binding module (BMod) selected from: iii) K-[BM]-DPSQS X a X b LLX c EAKKL X d X e X f Q (SEQ ID NO:1296), as presented in U.S.
- BMod amino acid sequence binding module
- the IL-17A binding polypeptide may comprise an amino acid sequence binding module (BMod) selected from: v) K-[BM]-QPEQS X a X b LLX c EAKKL X d X e X f Q (SEQ ID NO:1297), as presented in U.S.
- BMod amino acid sequence binding module
- sequence iv and vi) have at least at least 87%, such as at least 89%, such as at least 91%, such as at least 93%, such as at least 95%, such as at least 97% identity to a sequence defined by iii) or v), respectively.
- Xa in sequence iii) or v) is A.
- Xa in sequence iii) or v) is S.
- X b in sequence iii) or v) is N. In one embodiment, Xb in sequence iii) or v) is E. In one embodiment, Xc in sequence iii) or v) is A. In one embodiment, X c in sequence iii) or v) is S. In one embodiment, X c in sequence iii) or v) is C. In one embodiment, Xd in sequence iii) or v) is E. In one embodiment, X d in sequence iii) or v) is N. In one embodiment, X d in sequence iii) or v) is S.
- Xe in sequence iii) or v) is D. In one embodiment, Xe in sequence iii) or v) is E. In one embodiment, X e in sequence iii) or v) is S. In one embodiment, X d X e in sequence iii) or v) is selected from EE, ES, SD, SE and SS. In one embodiment, X d X e in sequence iii) or v) is ES. In one embodiment, X d X e in sequence iii) or v) is SE. In one embodiment, X d X e in sequence iii) or v) is SD.
- X f in sequence iii) or v) is A. In one embodiment, X f in sequence iii) or v) is S. In one embodiment, in sequence iii) or v), X a is A; X b is N; X c is A and X f is A. In one embodiment, in sequence iii) or v), Xa is S, Xb is E; Xc is A and X f is A. In one embodiment, in sequence iii) or v), X a is A; X b is N; X c is C and X f is A.
- X a is S, X b is E; X c is S and X f is S.
- Xa is S, Xb is E; Xc is S and X f is A.
- Xa is S, Xb is E; Xc is A and X f is S.
- X a is S, X b is E; X c is C and X f is S.
- Xa is A; Xb is N; Xc is A; X d X e is ND and X f is A.
- X a is S, X b is E; X c is A; X d X e is ND and X f is A.
- Xa is A; Xb is N; Xc is C; X d X e is ND and X f is A.
- X a is S, X b is E; X c is S, X d X e is ND and X f is S.
- Xa is S, Xb is E; Xc is S, X d X e is ND and X f is A.
- Xa is S, Xb is E; Xc is C; X d X e is ND and X f is S.
- X a is A; X b is N; X c is A; X d X e is SE and X f is A.
- Xa is S, Xb is E; Xc is A; X d X e is SE and X f is A.
- X a is A; X b is N; X c is C; X d X e is SE and X f is A.
- X a is S, X b is E; X c is S, X d X e is SE and X f is S.
- X a is S, X b is E; X c is A; X d X e is SE and X f is S.
- Xa is S, Xb is E; Xc is C; X d X e is SE and X f is S.
- Xa is A; Xb is N; Xc is A; X d X e is ES and X f is A.
- X a is S, X b is E; X c is A; X d X e is ES and X f is A.
- Xa is A; Xb is N; Xc is C; X d X e is ES and X f is A.
- X a is S, X b is E; X c is S, X d X e is ES and X f is S.
- Xa is S, Xb is E; Xc is C; X d X e is ES and X f is S.
- X a is A; X b is N; X c is A; X d X e is SD and X f is A.
- Xa is S, Xb is E; Xc is A; X d X e is SD and X f is A.
- X a is A; X b is N; X c is C; X d X e is SD and X f is A.
- Xa is S, Xb is E; Xc is S, X d X e is SD and X f is S.
- sequence iii) or v X a is S, X b is E; X c is A; X d X e is SD and X f is S.
- sequence iii) or v Xa is S, Xb is E; Xc is C; X d X e is SD and X f is S.
- sequence iii) corresponds to the sequence from position 7 to position 55 in a sequence selected from the group consisting of SEQ ID NO:1-1216 presented in FIG.1 of U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence iii) corresponds to the sequence from position 7 to position 55 in a sequence selected from the group consisting of SEQ ID NO:1-66, 1200, 1206 and 1214, presented in FIG. 1 of U.S. Patent No. 10,934,335, which is incorporated by reference in its entirety.
- sequence iii) corresponds to the sequence from position 7 to position 55 in a sequence selected from the group consisting of SEQ ID NO:1-66, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence iii) corresponds to the sequence from position 7 to position 55 in a sequence selected from the group consisting of SEQ ID NO:1-35, presented in U.S.
- sequence iii) corresponds to the sequence from position 7 to position 55 in a sequence selected from the group consisting of SEQ ID NO:1-27 presented in U.S. Patent No. 10,934,335, which is incorporated by reference in its entirety.
- sequence iii) corresponds to the sequence from position 7 to position 55 in a sequence selected from the group consisting of SEQ ID NO:1-10 presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence iii) corresponds to the sequence from position 7 to position 55 in a sequence selected from the group consisting of SEQ ID NO:1-7 presented in U.S.
- sequence iii) corresponds to the sequence from position 7 to position 55 in a sequence selected from the group consisting of SEQ ID NO:1-4 and in another embodiment, sequence iii) corresponds to the sequence from position 7 to position 55 in SEQ ID NO:1 presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- an IL-17A binding polypeptide which comprises an amino acid sequence selected from: vii) YA-[BMod]-AP (SEQ ID NO:1298), presented in U.S.
- an IL-17A binding polypeptide which comprises an amino acid sequence selected from: ix) FA-[BMod]-AP (SEQ ID NO:1299), presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety, wherein [BMod] is an IL-17A binding module as defined above; and x) an amino acid sequence which has at least 86% identity to a sequence defined by ix).
- an IL-17A binding polypeptide which comprises an amino acid sequence selected from: xi) FN-[BMod]-AP (SEQ ID NO:1300) presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety, wherein [BMod] is an IL-17A binding module as defined above; and xii) an amino acid sequence which has at least 86% identity to a sequence defined by xi).
- polypeptides comprising minor changes as compared to the above amino acid sequences without largely affecting the tertiary structure and the function thereof also fall within the scope of the present disclosure.
- the IL-17A binding polypeptides as defined above may for example have a sequence which is at least 88%, such as at least 90%, such as at least 92%, such as at least 94%, such as at least 96%, such as at least 98% identical to a sequence defined by vii), ix) or xi).
- the IL-17A binding motif may form part of a polypeptide comprising an amino acid sequence selected from: wherein [BM] is an IL-17A binding motif as defined above.
- the IL-17A binding polypeptide comprises an amino acid sequence selected from: • xiii) VDAKYAK-[BM]-DPSQSSELLSEAKKLNDSQAPK (SEQ ID NO:1281), presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety wherein [BM] is an IL-17A binding motif as defined above; and • xiv) an amino acid sequence which has at least 86% identity to the sequence defined in xiii).
- polypeptides comprising minor changes as compared to the above amino acid sequences without largely affecting the tertiary structure and the function thereof are also within the scope of the present disclosure.
- the IL-17A binding polypeptides as defined above may for example have a sequence which is at least 87%, such as at least 89%, such as at least 91%, such as at least 93%, such as at least 94%, such as at least 96%, such as at least 98% identical to the sequence defined by xiii).
- Sequence xiii) in such a polypeptide may be selected from the group consisting of SEQ ID NO:1-1216, presented in U.S. Patent No. 10,934,335, which is incorporated by reference in its entirety.
- sequence xiii) is selected from the group consisting of SEQ ID NO:1- 66, 1200, 1206 and 1214, presented in U.S. Patent No.
- sequence xiii) is selected from the group consisting of SEQ ID NO:1-66, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence xiii) is selected from the group consisting of SEQ ID NO:1-35, presented in U.S. Patent No. 10,934,335, which is incorporated by reference in its entirety.
- sequence xiii) is selected from the group consisting of SEQ ID NO:1-27, presented in U.S. Patent No. 10,934,335, which is incorporated by reference in its entirety.
- sequence xiii) is selected from the group consisting of SEQ ID NO:1- 10, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety. In one embodiment, sequence xiii) is selected from SEQ ID NO:1-7, presented in U.S. Patent No. 10,934,335, which is incorporated by reference in its entirety. In one embodiment, sequence xiii) is selected from the group consisting of SEQ ID NO:1-4, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety. In one embodiment, sequence xiii) is SEQ ID NO:1, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- the IL-17A binding polypeptide comprises an amino acid sequence selected from: xv) AEAKYAK-[BM]-DPSQSSELLSEAKKLNDSQAPK (SEQ ID NO:1259), presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety, wherein [BM] is an IL-17A binding motif as defined above; and xvi) an amino acid sequence which has at least 86% identity to the sequence defined in xv).
- polypeptides comprising minor changes as compared to the above amino acid sequences without largely affecting the tertiary structure and the function thereof are also within the scope of the present disclosure.
- the IL-17A binding polypeptides as defined above may for example have a sequence which is at least 87%, such as at least 89%, such as at least 91%, such as at least 93%, such as at least 94%, such as at least 96%, such as at least 98% identical to the sequence defined by xv).
- Sequence xv) in such a polypeptide may be selected from the group consisting of SEQ ID NO:1217-1222, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence xv) is selected from the group consisting of SEQ ID NO:1218-1222, presented in U.S.
- sequence xv) is selected from the group consisting of SEQ ID NO:1219-1222, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence xv) is selected from the group consisting of SEQ ID NO:1219 and SEQ ID NO:1222, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- sequence xv) is SEQ ID NO:1219, presented in U.S. Patent No.10,934,335, which is incorporated by reference in its entirety.
- the small size and robustness of the IL-17A binding domains of the present disclosure confer several advantages over conventional monoclonal antibody-based therapies. Such advantages include the possibility of subcutaneous (s.c.) administration at higher doses than antibodies, alternative routes of administration, flexibility in formatting for superior potency and absence of Fc-mediated side effects.
- the small size combined with potential for very high solubility (>100 mg/ml) and stability allows for extreme molar amounts of drug in a small volume for s.c. injections. For systemic administration, this suggests outpatient “home use” treatment using convenient small prefilled syringes or auto-injectors, with low volume and well tolerated administration of doses.
- the capacity for high molar concentrations in drug preparations in combination with the ability to retain functional stability in diverse formulations opens up for topical (skin, eye, lung) administration routes.
- Psoriasis, asthma, uveitis and dry eye syndrome are examples of indications where alternative administration routes could be especially relevant in IL-17A mediated disease.
- the IL-17A binding motif for the bispecific fusion protein of the invention are disclosed in U.S. Patent No.10,934,335 and U.S. Patent Publication No.2021/0253659, which are hereby incorporated in their entirety by reference herein.
- Albumin binding motif In another embodiment of the invention, the albumin binding motif consists of an amino acid sequence selected from (SEQ ID.
- the above defined class of sequence related polypeptides having a binding affinity for albumin is derived from a common parent polypeptide sequence, which folds into a three alpha helix bundle domain. More specifically, the polypeptides as described above are derived from a model building based on a structure of a complex between serum albumin and the albumin binding domain G148-GA3 (Lejon et al, J Biol Chem 279:42924-8, 2004), as well as analyses of binding and structural properties of a number of mutational variants of the common parent polypeptide sequence.
- the above defined amino acid sequence xvii) comprises amino acid substitutions as compared to the parent polypeptide sequence that result in a class of polypeptides which are expected to fold into an almost identical three helix bundle domain. While the parent polypeptide sequence already comprises a binding surface for interaction with albumin, that binding surface is modified by some of the substitutions according to the above definition.
- the substitutions according to the above definition provide an improved albumin binding ability as compared to the parent polypeptide sequence.
- the albumin binding polypeptides exhibit a set of characteristics, which, for example, make them suitable for use as fusion or conjugate partners for therapeutic molecules for human administration.
- the albumin binding polypeptides according to the present disclosure demonstrate, for example in comparison with related albumin binding polypeptides such as the albumin binding domain G148-GA3 and the albumin binding polypeptides disclosed in WO 09/016,043, at least five of the following six characteristics: •
- the polypeptides display a different surface compared to, for example, G148-GA3 and other bacterially derived albumin binding domains. The difference may decrease or eliminate any risk for antibody reactions in a subject, such as a human, which has been previously exposed to such bacterial proteins.
- the polypeptides comprise fewer potential T-cell epitopes than, for example, G148-GA3 and other related, but different, mutational variants of the common parent polypeptide sequence, and hence exhibit low immunogenicity when administered to a subject, such as a human.
- the polypeptides display a lower reactivity with circulating antibodies when administered to a subject, such as a human.
- antibody cross-reactivity is reduced as compared to, for example, antibody cross-reactivity caused by G148-GA3 as measured in a test set of human sera.
- the polypeptides have a high albumin binding ability, both in terms of a higher binding affinity, as defined by a KD value, and in terms of a slower off-rate, as defined by a k off value, than, for example, known naturally occurring albumin binding polypeptides, such as the albumin binding domains derived from bacterial proteins.
- the polypeptides comprise fewer amino acid residues that are associated with stability problems of polypeptides than, for example, known naturally occurring albumin binding polypeptides, such as the albumin binding domains derived from bacterial proteins.
- the polypeptides comprise, for example, no oxidation-prone methionines or tryptophanes and only one asparagine.
- the polypeptides have a higher structural stability, as defined by a melting point of above 55° C., than previous albumin binding polypeptides, such as those disclosed in WO 09/016,043.
- the albumin binding motif displays all six of the above listed characteristics.
- the albumin binding motif when bound to albumin, a more hydrophilic profile than, for example, previous albumin binding polypeptides, such as those disclosed in WO 09/016,043.
- the surface of the albumin binding polypeptide which is exposed to the surroundings when the polypeptide interacts with albumin comprises fewer amino acid residues that confer surface hydrophobicity.
- any polypeptide such as the albumin binding capacity of the polypeptides
- the function of any polypeptide is dependent on the tertiary structure of the polypeptide. It is however possible to make changes to the sequence of amino acids in an ⁇ -helical polypeptide without affecting the structure thereof (Taverna and Goldstein, J Mol Biol 315(3):479-84, 2002; He et al, Proc Natl Acad Sci USA 105(38):14412-17, 2008).
- the modified variants of i which are such that the resulting sequence is at least 95% identical to a sequence belonging to the class defined by i), are also encompassed by the current invention.
- amino acid residue belonging to a certain functional grouping of amino acid residues could be exchanged for another amino acid residue from the same functional group.
- % identical or % identity is calculated as follows.
- the query sequence is aligned to the target sequence using the CLUSTAL W algorithm (Thompson, J. D., Higgins, D. G. and Gibson, T. J., Nucleic Acids Research, 22: 4673-4680 (1994)).
- a comparison is made over the window corresponding to the shortest of the aligned sequences.
- the shortest of the aligned sequences may in some instances be the target sequence, such as the albumin binding polypeptide disclosed herein.
- the query sequence may constitute the shortest of the aligned sequences.
- the query sequence may for example consist of at least 10 amino acid residues, such as at least 20 amino acid residues, such as at least 30 amino acid residues, such as at least 40 amino acid residues, for example 45 amino acid residues.
- the amino acid residues at each position are compared, and the percentage of positions in the query sequence that have identical correspondences in the target sequence is reported as % identity.
- X 6 is E.
- X3 is S.
- X3 is E.
- X 7 is A.
- X14 is S.
- X14 is C.
- X 10 is A.
- X 10 is S.
- X 26 is D.
- X26 is E.
- X39 is D. In another embodiment of the albumin binding motif, described in xvii), X 39 is E. In another embodiment of the albumin binding motif, described in xvii), X 40 is A. In another embodiment of the albumin binding motif, described in xvii), X43 is A. In another embodiment of the albumin binding motif, described in xvii), X 44 is A. In another embodiment of the albumin binding motif, described in xvii), X 44 is S. In another embodiment of the albumin binding motif, the L residue in position 45 is present. In another embodiment of the albumin binding motif, described in xvii), the P residue in position 46 is present.
- the P residue in position 46 is absent.
- the albumin binding polypeptide, described in xvii) is subject to the proviso that X7 is neither L, E nor D.
- the albumin binding polypeptide may be prepared for conjugation with a suitable conjugation partner by the replacement of surface exposed amino acid residues with, for example, either a cysteine or a lysine. These replacements may be introduced into the N-terminal helix, i.e. helix one, of the polypeptide, which is the helix situated furthest away from the serum albumin when the albumin binding polypeptide is bound to serum albumin.
- a lysine residue in position X14 of the sequence defined in i) may be used to enable site-directed conjugation. This may furthermore be advantageous when the molecule is made by chemical peptide synthesis, since orthogonal protection of the epsilon-amino group of said lysine may be utilized.
- a cysteine residue may be introduced into the amino acid sequence to enable site-directed conjugation. For example, a cysteine residue may be introduced into any one of the positions X3, X 6 and/or X 14 in accordance with the above definition.
- Coupling of a conjugation partner to the epsilon-amine of a lysine or the thiol group of a cysteine represents two chemically different alternatives to obtain site-directed conjugation using an amino acid residue within the amino acid sequence xvii).
- other chemical alternatives for preparing an amino acid sequence for conjugation exist, and are as such also within the scope of the present disclosure.
- One example of such a chemistry is the click- like chemistry enabled by the introduction of a tyrosine as presented by Ban et al (J Am Chem Soc 132:1523-5, 2009).
- the albumin binding polypeptide comprises one or more additional amino acid residues positioned at the N- and/or the C-terminal of the sequence defined in xvii).
- additional amino acid residues may play a role in enhancing the binding of albumin by the polypeptide, and improving the conformational stability of the folded albumin binding domain, but may equally well serve other purposes, related for example to one or more of production, purification, stabilization in vivo or in vitro, coupling, labeling or detection of the polypeptide, as well as any combination thereof.
- Such additional amino acid residues may comprise one or more amino acid residue(s) added for purposes of chemical coupling, e.g.
- amino acids directly preceding or following the alpha helix at the N- or C-terminus of the amino acid sequence xvii) may thus in one embodiment affect the conformational stability.
- an amino acid residue which may contribute to improved conformational stability is a serine residue positioned at the N-terminal of the amino acid sequence i) as defined above.
- the N-terminal serine residue may in some cases form a canonical S-X-X-E capping box, by involving hydrogen bonding between the gamma oxygen of the serine side chain and the polypeptide backbone NH of the glutamic acid residue.
- the additional amino acids comprise at least one serine residue at the N-terminal of the polypeptide.
- the amino acid sequence is in other words preceded by one or more serine residue(s).
- the additional amino acids comprise a glycine residue at the N-terminal of the polypeptide. It is understood that the amino acid sequence xvii) may be preceded by one, two, three, four or any suitable number of amino acid residues.
- the amino acid sequence may be preceded by a single serine residue, a single glycine residue or a combination of the two, such as a glycine-serine (GS) combination or a glycine-serine-serine (GSS) combination.
- GS glycine-serine
- GSS glycine-serine-serine
- Examples of albumin binding polypeptides comprising additional amino residues at the N-terminal are set out in SEQ ID NO:145-163, such as in SEQ ID NO:145-148 and SEQ ID NO:162-163, as presented in U.S. Patent No.9,211,344, which is incorporated by reference in its entirety.
- the additional amino acid residues comprise a glutamic acid at the N-terminal of the polypeptide as defined by the sequence i).
- C-terminal capping may be exploited to improve stability of the third alpha helix of the three helix domain constituting the albumin binding polypeptide.
- a proline residue when present at the C-terminal of the amino acid sequence defined in i), may at least partly function as a capping residue.
- a lysine residue following the proline residue at the C-terminal may contribute to further stabilization of the third helix of the albumin binding polypeptide, by hydrogen bonding between the epsilon amino group of the lysine residue and the carbonyl groups of the amino acids located two and three residues before the lysine in the polypeptide backbone, e.g., when both L45 and P46 are present, the carbonyl groups of the leucine and alanine residues of the amino acid sequence defined in xvii).
- the additional amino acids comprise a lysine residue at the C-terminal of the polypeptide.
- the additional amino acids may be related to the production of the albumin binding polypeptide.
- an albumin binding polypeptide according to an embodiment in which P46 is present is produced by chemical peptide synthesis
- one or more optional amino acid residues following the C-terminal proline may provide advantages.
- Such additional amino acid residues may for example prevent formation of undesired substances, such as diketopiperazine at the dipeptide stage of the synthesis.
- One example of such an amino acid residue is glycine.
- the additional amino acids comprise a glycine residue at the C-terminal of the polypeptide, directly following the proline residue or following an additional lysine and/or glycine residue as accounted for above.
- polypeptide production may benefit from amidation of the C-terminal proline residue of the amino acid sequence i), when present.
- the C-terminal proline comprises an additional amine group at the carboxyl carbon.
- the above-mentioned addition of a glycine to the C-terminus or amidation of the proline, when present can also counter potential problems with racemization of the C-terminal amino acid residue.
- amidation of the C-terminal amino acid can be performed by several methods known in the art, e.g. through the use of amidating PAM enzyme.
- the albumin binding motifs for the bispecific fusion protein of the invention are disclosed in U.S. Patent Nos. 9,211,344, 10,329,331, 8,937,153, and 10,118,949, which are hereby incorporated in their entirety by reference herein.
- Pharmaceutical compositions Another aspect of the invention provides for a pharmaceutical composition comprising a bispecific fusion protein, preferably izokibep. In another aspect of the invention, the pharmaceutical composition comprises additional excipients.
- compositions intended for oral use may be prepared according to any method known in the art for the manufacture of pharmaceutical compositions and such compositions may contain one or more agents selected from sweetening agents, flavoring agents, coloring agents, and preserving agents, in order to provide pharmaceutically elegant and palatable preparations. Depending on the specific conditions being treated, such agents may be formulated into liquid or solid dosage forms and administered systemically or locally.
- the agents may be delivered, for example, in a timed- or sustained-slow release form as is known to those skilled in the art. Techniques for formulation and administration may be found in Remington: The Science and Practice of Pharmacy (20 th ed.) Lippincott, Williams & Wilkins (2000).
- Suitable routes may include oral, buccal, by inhalation spray, sublingual, rectal, transdermal, vaginal, transmucosal, nasal or intestinal administration; parenteral delivery, including intramuscular, subcutaneous, intramedullary injections, as well as intrathecal, direct intraventricular, intravenous, intra- articullar, intra -sternal, intra-synovial, intra-hepatic, intralesional, intracranial, intraperitoneal, intranasal, or intraocular injections or other modes of delivery.
- the agents of the disclosure may be formulated and diluted in aqueous solutions, such as in physiologically compatible buffers such as Hank’s solution, Ringer’s solution, or physiological saline buffer.
- penetrants appropriate to the barrier to be permeated are used in the formulation.
- penetrants are generally known in the art.
- Use of pharmaceutically acceptable inert carriers to formulate the compounds herein disclosed for the practice of the disclosure into dosages suitable for systemic administration is within the scope of the disclosure.
- the compositions of the present disclosure in particular, those formulated as solutions, may be administered parenterally, such as by intravenous injection.
- the compounds can be formulated readily using pharmaceutically acceptable carriers well known in the art into dosages suitable for oral administration.
- Such carriers enable the compounds of the disclosure to be formulated as tablets, pills, capsules, liquids, gels, syrups, slurries, suspensions and the like, for oral ingestion by a subject (e.g., patient) to be treated.
- the composition may be provided according to a dosing regimen.
- a dosing regimen may include one or more of a dosage, a dosing frequency, and a duration.
- the aforementioned bispecific fusion protein wherein the bispecific fusion protein comprises an IL-17A binding motif and an albumin binding motif is administered to the patients suffering from several chronic inflammatory diseases such as psoriasis, rheumatoid arthritis (RA), ankylosing spondylitis (AS), systemic lupus erythematosus (SLE) and multiple sclerosis (MS) (Miossec and Kolls, 2012, Nat Rev Drug Discov 11:763-7). Doses may be provided at any suitable interval.
- RA rheumatoid arthritis
- AS ankylosing spondylitis
- MS multiple sclerosis
- doses may be provided once per day, twice per day, three times per day, four times per day, five times per day, six times per day, eight times per day, once every 48 hours, once every 36 hours, once every 24 hours, once every 12 hours, once every 8 hours, once every 6 hours, once every 4 hours, once every 3 hours, once every two days, once every three days, once every four days, once every five days, once every week, twice per week, three times per week, four times per week, or five times per week.
- the aforementioned bispecific fusion protein wherein the bispecific fusion protein comprises an IL-17A binding motif and an albumin binding motif is administered to the patients suffering from ankylosing spondylitis (AS).
- AS kylosing spondylitis
- a pharmaceutical composition comprising a therapeutically effective of amount of the bispecific fusion protein is administered to a patient suffering from AS.
- a composition comprising a bispecific fusion protein, as described herein, and at least one pharmaceutically acceptable excipient or carrier.
- said composition further comprises at least one additional active agent, such as at least two additional active agents, such as at least three additional active agents.
- additional active agents that may prove useful in such a composition are the therapeutically active polypeptides, immune response modifying agents and toxic compounds described herein.
- a pharmaceutical composition comprising a therapeutically effective of amount of the bispecific fusion protein, preferably izokibep, is administered to a patient suffering from AS.
- the pharmaceutical composition comprising a therapeutically effective of amount of the bispecific fusion protein, preferably izokibep, is administered by a subcutaneous injection.
- the pharmaceutical composition comprises about 20 to about 400 mg izokibep.
- the pharmaceutical composition comprises about 40 mg, about 80 mg, or about 160 mg izokibep.
- the pharmaceutical composition comprising a therapeutically effective of amount of the bispecific fusion protein, preferably izokibep is administered as a subcutaneous injection once weekly, twice weekly, or once every four weeks.
- the pharmaceutical composition comprising a therapeutically effective of amount of the bispecific fusion protein, preferably izokibep is administered as a subcutaneous injection is administered for at least 16 weeks.
- the pharmaceutical composition comprising a therapeutically effective of amount of the bispecific fusion protein, preferably izokibep is administered as a subcutaneous injection is administered for at least 52 weeks.
- the pharmaceutical composition comprising about 40 mg izokibep is administered once a week to a patient suffering from AS.
- the pharmaceutical composition comprising about 160 mg izokibep is administered once a week to a patient suffering from AS.
- the administration of the pharmaceutical compositions comprising izokibep leads to a clinical response as assessed by Assessment of Spondyloarthritis International Society 40 (ASAS40) response after 16 weeks or 52 weeks in subjects with active AS.
- AS Spondyloarthritis International Society 40
- the patient suffering from AS achieves a ASA40 response after 16 weeks.
- the patient is suffering from axial spondyloarthritis (AxSpA).
- the patient is suffering from radiographic axial spondyloarthritis (r-AxSpA).
- the patient is suffering from non-radiographic axial spondyloarthritis (nr-AxSpA).
- the patient is administered the pharmaceutical compositions comprising izokibep suffering from AS had an inadequate response or intolerance to at least 2 Non-steroidal anti-inflammatory drugs (NSAIDs), or contraindication to NSAID therapy.
- the patient is administered the pharmaceutical compositions comprising izokibep suffering from AS is TNF ⁇ inhibitor-na ⁇ ve or may have received up to 2 prior TNF ⁇ inhibitor(s).
- the patient is administered the pharmaceutical compositions comprising izokibep suffering from AS had an inadequate response to any previous therapies, including a therapy by a biomolecule, or any other Janus Kinase (JAK) inhibitors.
- JK Janus Kinase
- Examples The examples provided herein are representative for the dosing regimens disclosed in the invention.
- An exemplary clinical dosing in accordance with the present disclosure is provided below. The study will include the following 3 periods: 1. Screening Period: Up to 35 days prior to baseline randomization. 2.
- Treatment Period 1 (Placebo-Controlled, Double-Blind Period): Day 0 to Week 16
- Cohort 1 Eligible subjects will be randomized 1:1:1:1 to receive 1 of 4 treatments (Izokibep 160 mg once every two weeks, izokibep 40 mg once every two weeks, izokibep 160 mg once every four weeks, or placebo Q2W), and will remain on their allowable background medication.
- Cohort 2 Eligible subjects will be randomized 1:1:1 to receive 1 of 3 treatments (izokibep 160 mg once a week, izokibep 40 mg once a week, or placebo once a week), and will remain on their allowable background medication.
- Treatment Period 1 ends at Week 16 after all trial assessments have been done and Treatment Period 2 starts at Week 16 with the IMP injection.
- Treatment Period 2 (Open-label Extension Period): Week 16 to Week 52
- Cohort 1 Subjects will receive izokibep 160 mg once every two weeks subcutaneous injection treatment in an open-label manner.
- Cohort 2 Subjects will receive izokibep 160 mg once a week subcutaneous treatment in an open-label manner.
- Inclusion Criteria 1. Male or female at least 18 years of age. 2.
- Subjects with active AS determined by documented radiologic evidence (X-ray) fulfilling the Modified New York criteria for AS (1984) and at least one SpA feature, according to ASAS criteria. 3. Subjects have moderate to severe active disease 4. Subjects must have inadequate response or intolerance to at least 2 NSAIDs, or contraindication to NSAID therapy. 5. Subjects may be TNF ⁇ inhibitor-na ⁇ ve or may have received up to 2 prior TNF ⁇ inhibitor(s).
- Exclusion Criteria 1. Subjects have active fibromyalgia or total spinal ankylosis ('bamboo spine'), or any other inflammatory arthritis. 2. Subjects have used medications in the manner as detailed by the exclusion criteria as detailed in the study protocol. 3.
- Subjects have received technetium-99 conjugated with methylene diphosphonate other than for diagnostic purpose within 5 years prior to baseline. 4. Have received any live (includes attenuated) vaccination within the 12 weeks prior to the baseline. 5. Subjects have received any non-biological therapy for AS not listed as detailed in the study protocol within or outside a clinical study in the 3 months or within 5 half-lives prior to the Baseline Visit (whichever is longer). 6. Subject has an active infection or history of infections 7. Have evidence of or test positive for hepatitis B virus (HBV) 8. Have evidence of or test positive for hepatitis C virus (HCV). 9. Have a historically positive human immunodeficiency virus (HIV) test or test positive at screening for HIV. 10.
- HBV hepatitis B virus
- HCV hepatitis C virus
- Subjects have known tuberculosis (TB) infection, at high risk of acquiring TB infection, or current or history of nontuberculous mycobacterium (NTMB) infection, or LTB. 11. Have a history of a lymphoproliferative disorder including lymphoma or current signs and symptoms suggestive of lymphoproliferative disease. 12. Subjects have active Crohn's disease (CD) or active ulcerative colitis (UC). 13. Subjects have active uveitis within 6 weeks prior to baseline. 14. Subjects have laboratory abnormalities at Screening. Dosing Regimen The dosing regimen in the various arms of clinical trials are provided below.
Landscapes
- Health & Medical Sciences (AREA)
- Chemical & Material Sciences (AREA)
- Organic Chemistry (AREA)
- Life Sciences & Earth Sciences (AREA)
- General Health & Medical Sciences (AREA)
- Medicinal Chemistry (AREA)
- Immunology (AREA)
- Proteomics, Peptides & Aminoacids (AREA)
- Genetics & Genomics (AREA)
- Biophysics (AREA)
- Molecular Biology (AREA)
- Biochemistry (AREA)
- Engineering & Computer Science (AREA)
- Bioinformatics & Cheminformatics (AREA)
- Gastroenterology & Hepatology (AREA)
- Veterinary Medicine (AREA)
- Pharmacology & Pharmacy (AREA)
- Animal Behavior & Ethology (AREA)
- Public Health (AREA)
- Nuclear Medicine, Radiotherapy & Molecular Imaging (AREA)
- General Chemical & Material Sciences (AREA)
- Chemical Kinetics & Catalysis (AREA)
- Transplantation (AREA)
- Epidemiology (AREA)
- Orthopedic Medicine & Surgery (AREA)
- Rheumatology (AREA)
- Physical Education & Sports Medicine (AREA)
- Peptides Or Proteins (AREA)
- Medicines That Contain Protein Lipid Enzymes And Other Medicines (AREA)
- Medicines Containing Antibodies Or Antigens For Use As Internal Diagnostic Agents (AREA)
Abstract
Description
Claims
Priority Applications (2)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| EP23785632.3A EP4504234A4 (en) | 2022-04-07 | 2023-04-06 | METHOD FOR THE TREATMENT OF ANKYLOSING SPONDYLITIS |
| US18/854,283 US20260028397A1 (en) | 2022-04-07 | 2023-04-06 | Methods of treating ankylosing spondylitis |
Applications Claiming Priority (2)
| Application Number | Priority Date | Filing Date | Title |
|---|---|---|---|
| US202263328533P | 2022-04-07 | 2022-04-07 | |
| US63/328,533 | 2022-04-07 |
Publications (2)
| Publication Number | Publication Date |
|---|---|
| WO2023196913A2 true WO2023196913A2 (en) | 2023-10-12 |
| WO2023196913A3 WO2023196913A3 (en) | 2023-11-23 |
Family
ID=88243803
Family Applications (1)
| Application Number | Title | Priority Date | Filing Date |
|---|---|---|---|
| PCT/US2023/065452 Ceased WO2023196913A2 (en) | 2022-04-07 | 2023-04-06 | Methods of treating ankylosing spondylitis |
Country Status (3)
| Country | Link |
|---|---|
| US (1) | US20260028397A1 (en) |
| EP (1) | EP4504234A4 (en) |
| WO (1) | WO2023196913A2 (en) |
Cited By (1)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| WO2025226984A1 (en) * | 2024-04-24 | 2025-10-30 | Mopac Biologics, Inc. | Human il-17 binding polypeptides |
Citations (1)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| US10934335B2 (en) | 2015-01-12 | 2021-03-02 | Affibody Ab | IL-17A-binding polypeptides |
-
2023
- 2023-04-06 US US18/854,283 patent/US20260028397A1/en active Pending
- 2023-04-06 WO PCT/US2023/065452 patent/WO2023196913A2/en not_active Ceased
- 2023-04-06 EP EP23785632.3A patent/EP4504234A4/en active Pending
Patent Citations (1)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| US10934335B2 (en) | 2015-01-12 | 2021-03-02 | Affibody Ab | IL-17A-binding polypeptides |
Cited By (1)
| Publication number | Priority date | Publication date | Assignee | Title |
|---|---|---|---|---|
| WO2025226984A1 (en) * | 2024-04-24 | 2025-10-30 | Mopac Biologics, Inc. | Human il-17 binding polypeptides |
Also Published As
| Publication number | Publication date |
|---|---|
| WO2023196913A3 (en) | 2023-11-23 |
| EP4504234A4 (en) | 2025-11-19 |
| EP4504234A2 (en) | 2025-02-12 |
| US20260028397A1 (en) | 2026-01-29 |
Similar Documents
| Publication | Publication Date | Title |
|---|---|---|
| JP4713809B2 (en) | Hepatitis B core antigen fusion protein | |
| CN105566497A (en) | Ferritin fusion proteins for use in vaccines and other applications | |
| JP2010155852A (en) | REVERSAL OF VIRALLY-INDUCED GENERALIZED SHOCK AND DISTRESS IN BREATHING BY BLOCKING LYMPHOTOXIN beta ROUTE | |
| AU758576B2 (en) | Chemokines with amino-terminal modifications | |
| JPH05508847A (en) | Transfer factors and usage | |
| KR20110030554A (en) | Anti-amyloid Immunogenic Compositions, Methods and Uses | |
| US20230399364A1 (en) | Immunogenic Coronavirus Fusion Proteins and Related Methods | |
| JP2021514354A5 (en) | ||
| JP7830450B2 (en) | Modified IL-2 molecules and their uses | |
| JP7801104B2 (en) | Reaction intermediates for producing polyethylene glycol (PEG)-interleukin 11 (IL-11) conjugates and methods for purifying PEG-IL-11 conjugates | |
| WO2023196913A2 (en) | Methods of treating ankylosing spondylitis | |
| CN1345336A (en) | Antibody and chemokine constructs and their use for treating autoimmune diseases | |
| US10058606B2 (en) | Hepatitis B therapeutic vaccines | |
| JP5414959B2 (en) | Pharmaceutical composition containing sFcγRIIb or sFcγRIII | |
| US12552848B2 (en) | Hydrochloride salts of C5a receptor agonist peptides | |
| RU2575796C2 (en) | Pegylated recombinant consensus interferon version conjugate and preparation method and use thereof | |
| RU2575796C9 (en) | Pegylated recombinant consensus interferon version conjugate and preparation method and use thereof | |
| JPS6117523A (en) | Broad-spectrum vaccine for gonorrhea | |
| CN101671390B (en) | Preparation and application of human interferon alpha derivative and polyethylene glycol modified substance thereof | |
| JPH08511542A (en) | Coil-Coil Stem Loop Mold | |
| JP2023524866A (en) | Formulations of anti-IL-33 antibodies | |
| JPH07508520A (en) | combination polypeptide antigen | |
| JP2025529128A (en) | Compositions and methods of use targeting apoptosis-associated speck-like proteins with caspase activation and recruitment domains (ASCs) | |
| WO1991008754A1 (en) | Medicinal application of m-csf | |
| US20150225478A1 (en) | Immunogenic and Prophylactic Compositions, Methods of Making Same, and Methods for Treating and Preventing TNF-Mediated Disease |
Legal Events
| Date | Code | Title | Description |
|---|---|---|---|
| 121 | Ep: the epo has been informed by wipo that ep was designated in this application |
Ref document number: 23785632 Country of ref document: EP Kind code of ref document: A2 |
|
| WWE | Wipo information: entry into national phase |
Ref document number: 2023785632 Country of ref document: EP |
|
| NENP | Non-entry into the national phase |
Ref country code: DE |
|
| ENP | Entry into the national phase |
Ref document number: 2023785632 Country of ref document: EP Effective date: 20241107 |
|
| 121 | Ep: the epo has been informed by wipo that ep was designated in this application |
Ref document number: 23785632 Country of ref document: EP Kind code of ref document: A2 |
