WO2024006339A1 - Method for purifying a pathogen genome sample - Google Patents
Method for purifying a pathogen genome sample Download PDFInfo
- Publication number
- WO2024006339A1 WO2024006339A1 PCT/US2023/026429 US2023026429W WO2024006339A1 WO 2024006339 A1 WO2024006339 A1 WO 2024006339A1 US 2023026429 W US2023026429 W US 2023026429W WO 2024006339 A1 WO2024006339 A1 WO 2024006339A1
- Authority
- WO
- WIPO (PCT)
- Prior art keywords
- recited
- activated carbon
- protein
- sample
- pathogen
- Prior art date
- Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)
- Ceased
Links
Classifications
-
- C—CHEMISTRY; METALLURGY
- C12—BIOCHEMISTRY; BEER; SPIRITS; WINE; VINEGAR; MICROBIOLOGY; ENZYMOLOGY; MUTATION OR GENETIC ENGINEERING
- C12N—MICROORGANISMS OR ENZYMES; COMPOSITIONS THEREOF; PROPAGATING, PRESERVING, OR MAINTAINING MICROORGANISMS; MUTATION OR GENETIC ENGINEERING; CULTURE MEDIA
- C12N15/00—Mutation or genetic engineering; DNA or RNA concerning genetic engineering, vectors, e.g. plasmids, or their isolation, preparation or purification; Use of hosts therefor
- C12N15/09—Recombinant DNA-technology
- C12N15/10—Processes for the isolation, preparation or purification of DNA or RNA
- C12N15/1003—Extracting or separating nucleic acids from biological samples, e.g. pure separation or isolation methods; Conditions, buffers or apparatuses therefor
-
- C—CHEMISTRY; METALLURGY
- C12—BIOCHEMISTRY; BEER; SPIRITS; WINE; VINEGAR; MICROBIOLOGY; ENZYMOLOGY; MUTATION OR GENETIC ENGINEERING
- C12N—MICROORGANISMS OR ENZYMES; COMPOSITIONS THEREOF; PROPAGATING, PRESERVING, OR MAINTAINING MICROORGANISMS; MUTATION OR GENETIC ENGINEERING; CULTURE MEDIA
- C12N15/00—Mutation or genetic engineering; DNA or RNA concerning genetic engineering, vectors, e.g. plasmids, or their isolation, preparation or purification; Use of hosts therefor
- C12N15/09—Recombinant DNA-technology
- C12N15/10—Processes for the isolation, preparation or purification of DNA or RNA
- C12N15/1003—Extracting or separating nucleic acids from biological samples, e.g. pure separation or isolation methods; Conditions, buffers or apparatuses therefor
- C12N15/1017—Extracting or separating nucleic acids from biological samples, e.g. pure separation or isolation methods; Conditions, buffers or apparatuses therefor by filtration, e.g. using filters, frits, membranes
-
- C—CHEMISTRY; METALLURGY
- C12—BIOCHEMISTRY; BEER; SPIRITS; WINE; VINEGAR; MICROBIOLOGY; ENZYMOLOGY; MUTATION OR GENETIC ENGINEERING
- C12N—MICROORGANISMS OR ENZYMES; COMPOSITIONS THEREOF; PROPAGATING, PRESERVING, OR MAINTAINING MICROORGANISMS; MUTATION OR GENETIC ENGINEERING; CULTURE MEDIA
- C12N2760/00—MICROORGANISMS OR ENZYMES; COMPOSITIONS THEREOF; PROPAGATING, PRESERVING, OR MAINTAINING MICROORGANISMS; MUTATION OR GENETIC ENGINEERING; CULTURE MEDIA ssRNA viruses negative-sense
- C12N2760/00011—Details
- C12N2760/16011—Orthomyxoviridae
- C12N2760/16111—Influenzavirus A, i.e. influenza A virus
- C12N2760/16121—Viruses as such, e.g. new isolates, mutants or their genomic sequences
-
- C—CHEMISTRY; METALLURGY
- C12—BIOCHEMISTRY; BEER; SPIRITS; WINE; VINEGAR; MICROBIOLOGY; ENZYMOLOGY; MUTATION OR GENETIC ENGINEERING
- C12N—MICROORGANISMS OR ENZYMES; COMPOSITIONS THEREOF; PROPAGATING, PRESERVING, OR MAINTAINING MICROORGANISMS; MUTATION OR GENETIC ENGINEERING; CULTURE MEDIA
- C12N2770/00—MICROORGANISMS OR ENZYMES; COMPOSITIONS THEREOF; PROPAGATING, PRESERVING, OR MAINTAINING MICROORGANISMS; MUTATION OR GENETIC ENGINEERING; CULTURE MEDIA ssRNA viruses positive-sense
- C12N2770/00011—Details
- C12N2770/00021—Viruses as such, e.g. new isolates, mutants or their genomic sequences
-
- C—CHEMISTRY; METALLURGY
- C12—BIOCHEMISTRY; BEER; SPIRITS; WINE; VINEGAR; MICROBIOLOGY; ENZYMOLOGY; MUTATION OR GENETIC ENGINEERING
- C12N—MICROORGANISMS OR ENZYMES; COMPOSITIONS THEREOF; PROPAGATING, PRESERVING, OR MAINTAINING MICROORGANISMS; MUTATION OR GENETIC ENGINEERING; CULTURE MEDIA
- C12N2770/00—MICROORGANISMS OR ENZYMES; COMPOSITIONS THEREOF; PROPAGATING, PRESERVING, OR MAINTAINING MICROORGANISMS; MUTATION OR GENETIC ENGINEERING; CULTURE MEDIA ssRNA viruses positive-sense
- C12N2770/00011—Details
- C12N2770/20011—Coronaviridae
- C12N2770/20021—Viruses as such, e.g. new isolates, mutants or their genomic sequences
-
- C—CHEMISTRY; METALLURGY
- C12—BIOCHEMISTRY; BEER; SPIRITS; WINE; VINEGAR; MICROBIOLOGY; ENZYMOLOGY; MUTATION OR GENETIC ENGINEERING
- C12Q—MEASURING OR TESTING PROCESSES INVOLVING ENZYMES, NUCLEIC ACIDS OR MICROORGANISMS; COMPOSITIONS OR TEST PAPERS THEREFOR; PROCESSES OF PREPARING SUCH COMPOSITIONS; CONDITION-RESPONSIVE CONTROL IN MICROBIOLOGICAL OR ENZYMOLOGICAL PROCESSES
- C12Q1/00—Measuring or testing processes involving enzymes, nucleic acids or microorganisms; Compositions therefor; Processes of preparing such compositions
- C12Q1/68—Measuring or testing processes involving enzymes, nucleic acids or microorganisms; Compositions therefor; Processes of preparing such compositions involving nucleic acids
- C12Q1/6806—Preparing nucleic acids for analysis, e.g. for polymerase chain reaction [PCR] assay
Definitions
- Activated carbon has been long known to adsorb viruses, which may retain their infectivity even after adsorption. However, upon release from the carbon, the viral genomes appear to be either adsorbed and/or destroyed by the activated carbon. The poor performance of this conventional methodology is demonstrated in an experiment where a conventional method of viral concentration using polyethylene glycol (PEG) was compared to activated carbon (FIG. 1).
- PEG polyethylene glycol
- FIG. 1 also presents a conventional PEG method for concentrating viruses. By omitting activated carbon, significant amounts of viral RNA could be isolated. While the PEG method is suitable in some situations, an improved method is therefore desired that provides a wider range of options for concentrating pathogen genomes.
- This disclosure provides a method for purifying a pathogen genome sample.
- the method traps pathogen particles on the surface of activated carbon.
- the activated carbon Prior to release of the pathogen particles, the activated carbon is treated with a blocking solution that prevents the activated carbon from degrading and/or binding the released pathogen nucleic acids. After treatment with the blocking solution, the pathogen particles are released from the activated carbon with a lysis reagent.
- the technical problem to be solved is the inability of conventional activated carbon methods to extract pathogen genomes without degradation and/or loss due to binding to the carbon surface.
- An advantage that may be realized in the practice of some embodiments of the method is that the method permits the use of activated carbon to extract pathogen genomes with dramatically reduced viral genome loss due to degradation and/or binding to the carbon surface, relative to conventional carbon-based attempts.
- Another advantage that may be realized in the practice of some embodiments of the method is that the method provides higher degrees of concentration than conventional PEG methods.
- a method for purifying a pathogen genome sample comprises sequential steps of: a) exposing activated carbon to a sample comprising a pathogen, thereby forming a carbon-pathogen complex; b) treating the carbon-pathogen complex with a blocking solution comprising a buffered, aqueous solution of amino acids; c) waiting a predetermined amount of time; d) removing the blocking solution from the carbon-pathogen complex; e) washing the carbon-pathogen complex with a buffered solution, the step of washing occurring at least once; f) treating with a lysis reagent to produce a released pathogen genome sample; and g) purifying the released pathogen genome sample.
- FIG. 1 is a graph showing detection of bovine coronavirus reconstituted in PBS buffer and concentrated using activated carbon and a conventional method that uses polyethylene glycol (PEG).
- PEG polyethylene glycol
- FIG. 2A depicts one possible mechanism of nucleic acids released from virus particles adsorbed onto solid phase exchange materials (SPEM) such as activated carbon.
- SPEM solid phase exchange materials
- FIG. 3 is a schematic of one filter for use with the disclosed method.
- FIG. 4 is a graph comparing different methods to quantify SARS-CoV-2
- RNA from wastewater samples obtained from two wastewater treatment plants (labeled 1 and 2) from New York City (NYC).
- the pair of black bars in the middle are samples collected on a different day.
- FIG. 5 is a graph showing stability of SARS-CoV-2 isolated from wastewater 48 h after adsorption. The carbon-adsorbed viruses were incubated for 48 h in blocking solution before lysis and RNA extraction.
- FIG. 6 is a graph showing recovery of Influenza A virus from a wastewater treatment plant in New York City (NYC) using the disclosed method.
- FIG. 10 is a graph showing detection of SARS-CoV-2 in hospital wastewater using an in situ trap.
- FIG. 11 is a graph showing detection of MPX in hospital wastewater using an in situ trap.
- FIG. 12 is a graph showing detection of Influenza A in hospital wastewater using an in situ trap.
- FIG. 13 is a schematic depiction of one pathogen trap for capturing viruses from water.
- FIG. 14 is a schematic depiction of one pathogen trap for capturing aerosolized viruses.
- This disclosure provides a method for purifying and protecting pathogen particles from a large volume and, in some embodiments, the subsequent extraction of pathogen genomes.
- the method uses a quick solid-phase exchange of pathogens suspended in solutions of low titer such as wastewater and environmental samples.
- the method is initiated by exposing activated carbon to a sample comprising a pathogen to form a carbon-pathogen complex.
- suitable activated carbons include activated charcoal (e.g. Sigma- Aldrich, C4386), which is granular carbon with high porosity, for adsorbing viruses.
- the majority of carbon particles are greater than 10 microns in diameter and more than 10-15% are greater than 74 microns in diameter with a surface area of approximately 1000-1200 (e.g. about 1100) m 2 per g.
- the exposing continues for at least 15 minutes. In another embodiment, the exposing continues at least 30 minutes.
- Activated fine carbon has different kinds of pores namely micropores ( ⁇ 2 nm in diameter), mesopores (2-50 nm) and macropores (>50 nm).
- micropores ⁇ 2 nm in diameter
- mesopores 2-50 nm
- macropores >50 nm.
- the percentage of these pores, and therefore the surface area available for binding, vary depending on the type of carbon and could be used to adsorb different molecules other than viruses.
- This blocking is achieved by facilitating the binding of amino acids and polypeptides to the potential nucleic acid-binding sites.
- a 20% (m/v) solution of tryptone e.g. BACTO ® Tryptone, GIBCO®
- PBS blocking solution
- Blocking solutions that block specific adsorption sites can be designed to facilitate selective adsorption of molecules of interest. Such targeted designs could be employed as molecular sieves to separate and/or purify molecules of interest.
- alternatives to tryptone including but not limited to other partially or fully digested protein products such as peptides, protein hydrolysates, peptone, casamino acids, yeast extract, beef extract, gelatin, meat extract, casein hydrolysate, com steep liquor, hydrolyzed vegetable proteins (soy, wheat, or corn), soy peptone, atholate (plant protein hydrolysate) etc. can be used.
- proteins including but not limited to lactalbumin, bovine serum albumin, egg albumin, whey protein, casein protein, soy protein, pea protein, rice protein, hemp protein, pumpkin seed protein, sunflower seed protein, peanut protein, sesame seed protein, almond protein etc. may be employed.
- the user waits for a predetermined amount of time (e.g. at least 1 minute) to permit absorption of the amino acid.
- a predetermined amount of time e.g. at least 1 minute
- the predetermined amount of time is at least 5 minutes. In another embodiment, the predetermined amount of time is at least 7 minutes.
- the blocking solution is then removed by, for example, filtration such that the now blocked carbon-pathogen complex is separated from the blocking solution.
- the steps of treating with the blocking solution, waiting a predetermined amount of time, and then removing the blocking solution are repeated at least once (i.e. at least two occurrences of the steps). In one embodiment, these steps are repeated at least twice (i.e. at least three occurrences of the steps). In yet another embodiment, these steps are repeated at least three times (i.e., at least four occurrences of the steps).
- TRIzol reagent (0.75 ml twice) was then added as a lysis reagent to the filter to open viral capsids and release the genomes. Vacuum was applied to collect TRIzol with viral genomes, which were then precipitated as per the manufacturer’s instructions.
- the disclosed method was used to concentrate SARS- CoV-2 and purify viral RNA from New York city (NYC) wastewater samples.
- the samples were collected by the Department of Environmental Protection (DEP) from various wastewater treatment plants (WWTP) as part of their surveillance program.
- DEP Department of Environmental Protection
- WWTP wastewater treatment plants
- the carbon-adsorbed SARS-CoV-2 viruses can be stored in blocking solution (20% tryptone in PBS) for a period of at least 48 h at 4 °C without any loss of genetic signal.
- the adsorbed viruses are stable in the blocking solution for 48 h at 4 °C. This is noteworthy because the virus appears to rapidly degrade overnight in pasteurized wastewater stored at 4 °C (data not shown).
- the method was also used to concentrate Influenza A virus and purify viral RNA from a wastewater treatment plant in New York City (NYC) showing results comparable to the PEG method.
- An in situ pathogen trap was designed by immobilizing activated carbon particles into housings (e.g. steel housings). These traps can be deployed into wastewater sources such as sewer outflows or manholes.
- in situ virus traps were used in wastewater outflows of New York City (NYC) hospitals. After placing the traps for 10 h in manholes, SARS-CoV-2 viruses were successfully concentrated, which was followed by purification and quantification of the viral RNA genomes (FIG. 9A and FIG. 9B). PMMoV viruses were also detected from the same traps indicating the ability of trapping different viruses at the same time.
- the in situ virus trap concentrates viruses at the source without the need for transporting hazardous wastewater into labs for processing.
- the trap is designed to replace composite autosamplers, which use large pumps installed near manholes to collect aliquots of wastewater over a long period of time.
- the in situ virus trap is much smaller and can be easily deployed inside a manhole. RNA isolated from in situ traps installed inside manholes were successfully sequenced to identify variants.
- the assembled housings after being tied in a bunch, can be easily deployed into water sources such as sewage manholes or natural water bodies such as lakes or rivers. This design minimizes resistance to flowing water and the cartridges are free to move independently of each other. This prevents the accumulation of solid debris over the cartridges and allows efficient capture of target microorganisms.
- the activated carbon was then soaked in 5 ml blocking solution (20% tryptone in PBS) for 5 min. Vacuum was applied to drain the blocking solution and this was repeated for a total of four soakings. After draining the blocking solution, 5 ml of PBS was added to the carbon particles to soak for 2 min. Vacuum was applied to drain the PBS and a fresh 5 ml aliquot is added. This was repeated once more, and the vacuum was applied for an extra 30 s to remove any extra PBS. Several 10-ml aliquots of deionized (DI) water were used to transfer all the particles from the filter column into a fresh 50 ml tube.
- DI deionized
- the tube was decanted to remove all DI water and 10 ml of fresh DI water was added to the carbon particles for total nucleic acid extraction using the Promega WIZARD® Enviro TNA kit. 200 pl of protease provided in the kit was then added followed by gentle swirling and incubation at room temperature for 30 min. 3 ml of binding buffer 1 (BBD), 250 ⁇ l of Binding buffer 2 (BBE), and 12 ml of isopropanol was added, and the contents were mixed by gently inverting the tubes. The tubes were then centrifuged at 3000 xg for 10 mins. The supernatant was decanted into a Promega PUREYIELDTM binding column taking care to not transfer any activated carbon.
- BBD binding buffer 1
- BBE Binding buffer 2
- 12 ml of isopropanol was added, and the contents were mixed by gently inverting the tubes.
- the tubes were then centrifuged at 3000 xg for 10 mins. The supern
- a raw water sample may be automatically processed in a device such as the device of FIG. 13.
- the raw sample can be filtered, then passed through a column packed with activated carbon and subsequently this filtered water can be released back into the pipes.
- the viruses adsorbed inside the carbon column can be brought back for further processing, thus avoiding any liquid handling, splashing, or spillage.
- an automated or remote-controlled robot is used to collect wastewater samples from the pipes.
- Using such robots permits one to collect wastewater samples from locations (e.g. sewer pipes or manholes) closer to the source than a wastewater treatment plant and, thus, allows a more precise spatial resolution of disease outbreaks.
- locations e.g. sewer pipes or manholes
- FIG. 14 depicts a trap designed for safely trapping viruses contained in aerosols.
- a vacuum pump draws air into an air trap containing activated carbon suspended in buffer.
- the air bubbles result in mixing of the activated carbon particles, maximizing the surface area available for adsorption.
- the aerosols entering the trap mix with the buffer allowing adsorption of viruses as well as other microorganisms on to the activated carbon particles.
- the air leaving the trap can also aerosolize, the high affinity of activated carbon minimizes the escape of adsorbed particles.
- the air leaving the trap can be passed through a filter to capture any aerosols that might possibly escape. Such traps could be used for surveillance of crowded indoor facilities as well as outdoors.
- Activated carbon can be used to adsorb a wide range of viruses from phages to SARS-CoV-2.
- viruses from environmental samples can be easily concentrated for nucleic acid purification. This is a useful tool in virome studies of environments such as rivers, lakes, or oceans, where low viral titers require processing of large sample volumes.
- This method can also be used to concentrate other microorganisms, such as pathogenic bacteria, for subsequent RNA purification when they are present in extremely low numbers.
