  • the subject of the present invention is a magnetic material of the garnet type, a Faraday magnetic film with high rotation comprising such a material and its manufacturing process.
  • the principle of such devices is to obtain a light contrast by using the Faraday effect induced on a monochromatic light when passing through a magnetic material.
  • a transparent monocrystalline substrate is used on which is deposited a thin monocrystalline layer of ferrimagnetic garnet in which the magnetization is normal to the plane, this layer is subdivided by etching into magnetic elementary cells whose magnetization can be oriented in a one way or the other.
  • These cells can thus be viewed in polarized light thanks to the Faraday effect: cells oriented in one direction will thus appear in clear, while cells oriented in the other direction will appear in dark.
  • this result is obtained by magnetic effect by selectively activating, in the presence of a polarization field, thin conductors deposited on the magnetic layer in two independent and perpendicular networks, surrounding the elementary magnetic cells.
  • the magnetic material used to produce the film must have very precise characteristics, but these are different depending on whether the thermomagnetic effect or the magnetic effect is used.
  • the reversal of the direction of magnetization is obtained by the application of a polarization field associated with a localized heating pulse on certain cells. Therefore, the material must have a compensation temperature close to ambient temperature so that the action of the applied external field is zero on the unheated cells, which occurs when one is in the vicinity of the compensation temperature. where the result of the magnetizations of the garnet sub-networks cancels out and nullifies the action of an external field.
  • the magnetic cells which will have been brought to a higher temperature, will see their magnetization align in the direction of the field applied simultaneously and one will thus obtain the reversal of the direction of the magnetization.
  • Magnetic garnets capable of meeting these characteristics correspond to composition (GdBi) 3 (FeGaAI) 5 0 12 .
  • the switching of these is done using currents flowing in crossed conductors in the presence of a polarization field.
  • the magnetic material used must have characteristics very different from those of materials using the thermomagnetic effect. In fact, this material must not have a compensation temperature close to ambient temperature, but it must have a low magnetization and a low anisotropy.
  • the use of the second technique proves to be particularly advantageous since it makes it possible to obtain much more quickly the reversal of the direction of magnetization of the magnetic cells, which constitutes an important advantage, in particular in display devices.
  • the present invention specifically relates to magnetic materials with high Faraday rotation, therefore with a high proportion of bismuth, capable of being used in devices using this second technique for switching magnetic cells.
  • the magnetic material according to the invention is characterized in that it corresponds to the formula: in which M represents either one or more rare earth elements chosen from lutetium, thulium and ytterbium, or yttrium, and xi, x 2 , y 1 and y 2 are such that: provided that y i and y 2 are not both equal to 0 and that y i + y 2 is at most equal to 1.
  • the magnetic material of the invention is thus a garnet of the Gd 2 Bii Fe 5 Oi 2 type in which part of the gadolinium has been replaced, on the one hand, by at least one element of the rare earths belonging to the lutetium group, thulium, ytterbium or by yttrium, and, on the other hand, by praseodymium, and in which part of the iron has been replaced by a non-magnetic element such as gallium and / or aluminum.
  • the presence either of at least one element of rare earths belonging to the group of lutetium, thulium, ytterbium, or of yttrium makes it possible to reduce the compensation temperature below the ambient temperature;
  • the presence of gallium and / or aluminum makes it possible to adjust the magnetization;
  • the presence of praseodymium makes it possible to adjust the uniaxial magnetic anisotropy field of the material to any value between 0 and 2 ⁇ 10 5 ⁇ A ⁇ m -1 , while retaining the optimized magneto-optical properties of the material due in particular to the presence of bismuth, gallium and / or aluminum, and one or more rare earths chosen from Lu, Tm, Yb or Y.
  • a single element of rare earths for example thulium, is used to decrease the compensation temperature.
  • rare earth elements chosen from Lu, Tm, Yb or Y
  • their respective contents (in atoms) in the material are such that the sum of these contents corresponds to x i .
  • a single element is generally used to adjust the magnetization. This can in particular be gallium, y 2 being equal to 0 in the formula given above.
  • Magnetic materials of this type can be obtained by epitaxy on a substrate. This makes it possible to obtain magnetic films with high Faraday rotation constituted by a thin monocrystalline layer of a magnetic material corresponding to the formula given above and by its non-magnetic monocrystalline substrate.
  • the substrate used for the epitaxy has practically the same crystal lattice constant as the magnetic material to be deposited.
  • the conventional technique for the deposition by epitaxy in the liquid phase of the layer, the conventional technique is used which consists in preparing an epitaxy bath from the oxides of the various constituents of the layer to be deposited, ie a bath containing gadolinium oxide, praseodymium oxide, at least one oxide of a metal M, bismuth oxide, iron oxide, gallium oxide and / or aluminum oxide and use is made a solvent for dissolving these different oxides.
  • This solvent can in particular be a mixture of lead oxide and boron oxide.
  • the quantities of the various oxides are such that they correspond to the composition of the layer which it is desired to deposit.
  • a substrate is then introduced into the bath by driving it in rotation and the deposition temperature Td is adjusted as a function of the saturation temperature Ts of the bath, in order to obtain the growth of a monocrystalline layer of desired composition.
  • the deposition temperature is generally 10 to 30 ° C lower than the saturation temperature.
  • the crucible is then introduced into an oven at 1000 ° C for several hours to melt the mixture, then it is subjected to stirring using a platinum stirrer and the temperature of the mixture is brought back to 950 ° C.
  • the stirring is continued mechanical for 4 h and after removing the agitator, the temperature of the bath is brought down as quickly as possible to 800 ° C.
  • a polished substrate is then introduced into the bath, of composition (Gd Ca) 3 (Ga Mg Zr) s O 12 oriented (111) having a diameter of 5.08 cm and a thickness of 500 ⁇ m, by dipping it horizontally in the bath and subjecting it to a rotational movement of 80 revolutions / minute.
  • the substrate-magnetic layer assembly is extracted from the bath without rotation, then it is subjected to an accelerated rotational movement up to 900 rpm to eject the remainder of the solvent by centrifugation, and it is taken out finally from the oven.
  • the epitaxial layer corresponds to the composition Bi 1 Gd 1.4 Tm 0.4 Pr 0.2 Fe 4.5 Ga 0.5 O 12 and its magnetic characteristics are given in the attached table. It also has a Faraday ⁇ f rotation of 1,750,000 ° / m measured at a wavelength of 632.8nm and an absorption a of 100,000 / m at this same wavelength.
  • the anisotropy constant Ku was determined from the following formula: in which H k represents the uniaxial anisotropy field and M s the saturation magnetic induction, in order to take account of the value of the saturation magnetic induction which can vary from one film to another.
  • the anisotropy constant of the film decreases sharply when the praseodymium content of the bath is increased and consequently the praseodymium content of the film.
  • the films obtained all have a Faraday rotation measured at 6328 A (632.8 nm) of approximately 17500 ° / cm.
